Omron G3F - Output

216 Solid State Relays G3@-VD G3F/G3FD
Note: Constant-current input circuit.
Output
G3F-203SLN-VD 5 VDC 4 to 6 VDC 390 Ω±20% 4 VDC max. 1 VDC min.
12 VDC 9.6 to 14.4 VDC 900
Ω±20% 9.6 VDC max.
24 VDC 19.2 to 28.8 VDC 2 k
Ω±20% 19.2 VDC max.
G3FD-X03SN-VD 5 to 24 VDC 4 to 28 VDC
1.5 k
Ω
+20%
/
–10%
4 VDC max.
G3FD-102SN-VD 5 to 24 VDC 4 to 28 VDC
1.5 k
Ω
+20%
/
–10%
4 VDC max.
100/110 VAC 75 to 125 VAC 41 k
Ω±20% 75 VAC max. 20 VAC min.
200/220 VAC 150 to 250 VAC 72 k
Ω±20% 150 VAC max. 40 VAC min.
G3F-203S-VD 4 to 24 VDC 3 to 28 VDC 15 mA max. (See note.) 3 VDC max. 1 VDC min.
G3F-203SL-VD 5 VDC 4 to 6 VDC 390
Ω±20% 4 VDC max.
12 VDC 9.6 to 14.4 VDC 900
Ω±20% 9.6 VDC max.
24 VDC 19.2 to 28.8 VDC 2 k
Ω±20% 19.2 VDC max.
G3FD-X03S-VD 4 to 24 VDC 3 to 28 VDC
1.5 k
Ω
+20%
/
–10%
3 VDC max.
G3FD-102S-VD
Model Rated voltage Operating voltage Impedance Voltage level
Must operate voltage Must release voltage
Model Rated load
voltage
Applicable load
Load voltage range Load current Inrush current
G3F-203SN-VD
G3F-203SLN-VD
G3F-203S-VD
G3F-203SL-VD
100 to 240 VAC 75 to 264 VAC 0.1 to 3 A 45 A (60 Hz, 1 cycle)
G3F-203SN-VD 100 to 240 VAC 75 to 264 VAC 0.1 to 2 A 45 A (60 Hz, 1 cycle)
G3FD-X03SN-VD
G3FD-X03S-VD
4 to 48 VDC 3 to 52.8 VDC 0.1 to 3 A 18 A (10 ms)
G3FD-102SN-VD
G3FD-102S-VD
5 to 110 VDC 3 to 125 VDC 0.1 to 2 A 10 A (10 ms)
