10
BATTERY INSTALLATION
1. Remove the Screw on the Battery Cover
located on the back of the main unit.
Use the supplied screwdriver or use a
commercially available small screwdriver to
remove the screw on the battery cover.
2. Open the Battery Cover.
3. Insert the battery.
Place the positive (+) side of the battery
(CR2032) upward. Insert the battery in the
direction of the arrow as illustrated.
4. Replace the Battery Cover.
Insert the projected portion of the battery cover
as illustrated.
Tighten the screw on the Battery Cover.
NOTES:
• After installing the battery, set the time of
day, weight and stride length.
• Remove the protective lm from the face
of the display.
Operating Instructions
