Omron H3DS Series User Manual

H3DS-F
H3DS-F
20
Dimensions
H3DS-FL
Surface color: Light gray 5Y7/1 (OMRON)
H3DS-FLC
17.5 73
80
44
68
17.5 73
45 80
44
68
45
Surface color: Light gray 5Y7/1 (OMRON)
Installation
Terminal Arrangement
15
18 16
18 16 A2
A1 15
(See note 2.)
B1
L
15
18 16
H3DS-FLC
A1 15 B1
18 16 A2
H3DS-FL
Note: 1. If voltage is applied to terminal B1, or if terminals A1 and B1 are shorted, the operating mode is switched to flicker-ON start mode. If
these terminals are disconnected, the mode switches to flicker-OFF start mode.
2. DC supply voltage does not require the designation of polarity .

Omron H3DS Series Specifications

General

Type	Solid-state Timer
Operating Temperature	-10°C to 55°C
Output Type	Relay
Terminal Type	Screw terminals
Storage Temperature	-25°C to 65°C
Mounting	DIN Rail
Output	SPDT
Functions	On-Delay, Off-Delay, Interval, One-Shot
Protection Rating	IP20
Contact Form	SPDT
