H3DS-X
H3DS-X
31
I/O Functions
Inputs ---
Outputs Control
output
Outputs
are turned ON when the preset value is reached.
Basic Operation
Setting
of Selector
The
selectors can be turned clockwise and counterclockwise to se
-
lect
the desired time scale, or operating mode.
Each
selector has a snap mechanism that secures the selector at a
given
position.
Set the selector at a position at which it is secured.
Do
not set it midway between two securing positions or a malfunc
-
tion
could result from improper setting.
Selection of T
ime Scale
The time scale is selected by turning the time scale selector. The
time scales will appear in the
following order in the time scale dis
-
play window on the left of the selector:
1 s, 0.1 s, 1 h, 0.1 h, 10 h, 1 h, 1 m, 0.1 m.
Note: The
time scale “1h” appears twice.
Both instances indicate
exactly
the same time scale.
Time scale display
window and selector
Locking/Unlocking
of Selectors and T
ime Setting Dial
The
time setting dial
and time scale selector can be locked using the
Y92S-38 Lock Key
, a special pen type tool that is sold separately
. T
o
lock
the dial or selectors, insert the
Lock Key in the keyhole to the
lower
right of the dial or selector and turn it clockwise until the dial or
selector
is completely covered with the red cover
. T
o unlock, turn the
Lock
Key in the opposite direction.
Key hole
Timing Charts
Rt
0.1 s min.
Rt: Resetting time
Power
(A1 and A2)
Output
Indicator
ON
OFF
Set time
To Next Page
