H5CC
66
*1. Inrush current will flow for a short time when the power supply is turned ON.
Inrush Current (Reference Values)
*2. The display is lit only when the power is ON. Nothing is displayed when power is OFF.
Item Models H5CC-AWSD
Classification Digital Timer with two-stage setting, and forecast output
Ratings
Power supply voltage 12 to 48 VDC/24 VAC 50/60 Hz
Allowable voltage
fluctuation range
85% to 110% of rated supply voltage (90% to 110% at 12 to 48 VDC)
Power consumption Approx. 5.32 VA/3.17 W at 24 VAC/12 to 48 VDC *1
Mounting method Flush mounting
External connections Screw terminals
Degree of protection IEC IP66 for panel surface only and when Y92S-P6 Waterproof Packing is used
Time range
0.001 s to 999.999 s, 0.01 s to 9999.99 s, 0.1 s to 99999.9 s, 1 s to 999999 s, 1 s to 99 h 59 min 59 s,
0.1 min to 99999.9 min, 1 min to 999999 min, 1 min to 9999 h 59 min, 0.1 h to 99999.9h, 1 h to 999999 h
Timer mode Elapsed time (Up)
Inputs
Input signals Signal, reset, gate
Input method
No-voltage (NPN) input/voltage (PNP) input (switchable)
No-voltage input ON impedance: 1 kΩ max. (Leaka
ge current: 12 mA when 0 Ω)
ON residual voltage: 3 V max.
OFF impedance: 100 kΩ min.
Voltage input High (logic) level: 4.5 to 30 VDC
Low (logic) level: 0 to 2 VDC (Input resistance: approx. 4.7 kΩ)
Signal, reset, gate Minimum input signal width: 1 or 20 ms (selectable, same for all input)
Reset system Power resets (only for A mode), external and manual reset
Power reset Minimum power-opening time: 0.5 s (except for F-1 mode)
Reset voltage 10% max. of power supply voltage
Sensor waiting time 250 ms max. (Control output is turned OFF and no input is accepted during sensor waiting time.)
Outputs
Output modes A, F-1
Output type
Transistor output: NPN open collector,
100 mA at 30 VDC max.
residual voltage: 1.5 VDC max. (Approx. 1 V)
Leakage current: 0.1 mA max.
Display
7-segment, negative transmissive LCD;
Present value: 10-mm-high characters, white Set value: 6-mm-high characters, green *2
Memory backup
No-volatile memory (overwrites: 100,000 times min.)
that can store data for 10 years min.
Operating temperature range -10 to 55°C (-10 to 50°C if timers are mounted side by side) (with no icing or condensation)
Storage temperature range -25 to 70°C (with no icing or condensation)
Operating humidity range 25% to 85%
Case color Black (N1.5)
Attachments Waterproof packing, flush mounting adapter, terminal cover
Voltage Applied voltage
Inrush current
(peak value)
Time
12 to 48 VDC/24 VAC
52.8 VAC 13.6 A 0.88 ms
42.8 VDC 12.9 A 0.80 ms
