H2C
H2C
213
Engineering Data
Switching operations (x 10 )
3
Load current (A)
Switching operations (x 10 )
3
Load current (A)
Nomenclature
Time range
selector
Timing operation
indicator
Rated voltage
color code
Operation
Timing Chart
H2C-8
ON-delay 8-pin Round Socket
H2C(-F) H2C-(F)R
Rt: Resetting time
H2C-8R
OFF-delay 8-pin Round Socket
Rt: Resetting time
Note: For the types rated at 24 and 48 VAC, the timing operation indicator is not equipped.
Set time Rt Set time
Rt
Set time (T)
Rt
Rt
Power failure
time (t)
Rt
T+t
Rt
Set time Set time
Rt
Rt: Resetting time
(see note)
Rt: Resetting time(see note)
Rt
Set time (T)
Rt Rt
T+t
Power failure
time (t)
To Next Page
