14 Multifunction Digital Timer H5CX-A/-L
■ Dimensions with Front Connecting Socket
Note: These dimensions vary with the kind of DIN track (reference value).
■ Accessories (Order Separately)
Note: All units are in millimeters unless otherwise indicated.
112
1
09
.7
1
03
.
2
1
00
.
9
9
2.
3
90
P2
C
F-11
-
@
P2
C
F-11
-
@
P2
C
F-
08-
@
H
5C
X
-
A11
/-
A11
S
H
5C
X-
A11D
/-
A11
SD
L
8
@
20.3 max.
7.8
3
4.5
35.4
4
40±0.2
40±0.2
7.8
4
35.4
20.3
19
3
1.3
5
4.5
70 max.
50 max.
20.3 max.
Track Mounting/Front Connecting Socket
P2CF-08
P2CF-08-E (Finger Safe Terminal Type)
Conforming to VDE0106/P100
Surface Mounting Holes
Two, 4.5 dia. or two, M4
50 max.
70 max.
21.5 max.
Terminal Arrangement/
Internal Connections
(Top View)
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes

Omron H5CX Specifications

General

Time Range	0.001 s to 9999 h
Mounting Method	Flush mounting
Output Type	Relay or Transistor
Control Output	Relay or Transistor
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Input Type	NPN or PNP
Power Supply Voltage	24V AC/DC, 100-240V AC
Operating Voltage Range	85% to 110% of rated voltage
Operating Modes	ON-delay, One-shot, Interval
Contact Rating	5 A at 250 VAC
Mounting	Panel
Dimensions	48 x 48 mm
Protection Structure	IP66 (front panel)
