16 Multifunction Digital Timer H5CX-A/-L
Note: 1. Depending on the operating environment, the condition of
resin products may deteriorate, and may shrink or become
harder. Therefore, it is recommended that resin products
are replaced regularly.
2. The H5CX’s panel surface is water-resistive (conforming to
IP66) and so even if drops of water penetrate the gaps be-
tween the keys, there will be no adverse effect on internal
circuits. If, however, there is a possibility of oil being present
on the operator’s hands, use the Soft Cover. The Soft Cover
ensures protection equivalent to IP54F against oil. Do not,
however, use the H5CX in locations where it would come in
direct contact with oil.
Note: Order the Flush Mounting Adapter separately if it is lost or dam-
aged.
Note: Use Waterproof Packing to provide a level of water protection
that complies with NEMA4, UL Type 4X, or IP66 standards. Or-
der the Waterproof Packing separately if it is lost or damaged.
Depending on the operating environment, the Waterproof
Packing may deteriorate, contract, or harden and so regular re-
placement is recommended.
Hard Cover
Y92A-48
Soft Cover
Y92A-48F1
Y92F-30
Flush Mounting Adapter
(provided with H5CX-A@ models)
Waterproof Packing
(provided with H5CX-A@ models)
Y92S-29
4.5
15 25 25
25
25
*
10
10
7.3±0.15
35±0.3
27±0.15
1
4.5
15 25 25
25 25
15
10 10
1,000
27
24
16
29.2
1
1.5
50
11.5
10
6.2
1.8
1
35.5 35.3
1.8
1.3
4.8
5
16
12
44.3
16.5
10
34.8
35±0.3
Mounting Track
PFP-100N, PFP-50N
PFP-100N2
End Plate
PFP-M
Spacer
PFP-S
1,000 (500)
(See note.)
Note: The values shown in parentheses are for the PFP-50N.
M4 x 8
pan head
screw
