Omron H7CX Series User Manual

39
H7CXH7CX
Mounting Track
PFP-100N, PFP-50N
PFP-100N2
End Plate
PFP-M
Spacer
PFP-S
4.5
15 25 25
25
25
*
10
10
7.3±0.15
35±0.3
27±0.15
1
4.5
15 25 25
25 25
15
10 10
1,000
27
24
16
29.2
1
1.5
50
11.5
M4 x 8
pan head
screw
10
6.2
1.8
1
35.5 35.3
1.8
1.3
4.8
5
16
12
44.3
16.5
10
34.8
1,000 (500)
(see note)
Note: The values shown in parentheses are for the PFP-50N.
35±0.3

Omron H7CX Series Specifications

General

Input Signal	Contact
Power Supply	12-24 VDC or 100-240 VAC
Output	Relay
Mounting	Panel mount
Storage Temperature	-25 to 65°C (with no icing or condensation)
Weight	200 g
