14
N
HOW TO APPLY THE CUFF
4. Align the Artery Position Mark
with the brachial artery.
5. Wrap the cuff snugly using both hands
and securely fasten it with the Velcro™
tape. At this time, the lower edge of
the cuff must be placed 1/2" to 1"
above the inner side of elbow joint.
• If the INDEX is positioned outside the RANGE, select the cuff suitable for the
patient’s arm circumference and wrap it again.
• Wrap the cuff so that you can insert only one finger between the cuff and arm.
6. Keep the level of the cuff at the
same level as the heart during the
measurement.
3. Place the right or left hand of the patient
with the palm of hand facing upward.
1/2"-1"
HEM-907-Z2_E_M.qxd 09.8.28 11:45 AM Page 14
To Next Page
