10-4
Mounted Objects Section 8-2
Additional Informa-
tion for DeviceNet
DeviceNet Object (0x03)
Assembly Object (0x04)
Object class Attribute Not supported
Service Not supported
Object
instance
Attribute ID Contents Get (read) Set (write) Value
1MAC ID No No
2 Baud rate Yes No
3 BOI Yes No 00 (hexadecimal)
4 Bus Off counter No No
5 Allocation information Yes No
Service DeviceNet service Parameter option
0E Get_Attribute_Single None
4B Allocate_Master/
Slave_Connection_Set
None
4C Release_Master/
Slave_Connection_Set
None
Object class Attribute Not supported
Service Not supported
Object instance
100: IN Area 1
101: IN Area 2
110: OUT Area 1
Attribute ID Contents Get (read) Set (write) Value
1 Number of members in list No No
2 Member list No No
3Data Yes No
Service DeviceNet service Parameter option
0E Get_Attribute_Single None
