Omron K3HB-R User Manual

10-5
Mounted Objects Section 8-2
Additional Informa-
tion for DeviceNet
Connection Object (0x05)
Object class Attribute Not supported
Service Not supported
Maximum number of active
connections
1
Object
instance 1
Section Information Maximum number of instances
Instance type Explicit Message 1
Production
trigger
Cyclic
Transport type Server
Transport
class
3
Attribute ID Contents Get (read) Set (write) Value
1 State Yes No
2 Instance type Yes No 00 (hexadecimal)
3 Transport class trigger Yes No 83 (hexadecimal)
4 Produced connection ID Yes No
5 Consumed connection ID Yes No
6 Initial comm. characteris-
tics
Yes No 21 (hexadecimal)
7 Produced connection size Yes No 0176 (hexadecimal)
8 Consumed connection
size
Ye s No
9 Expected packet rate Yes Yes 01 (hexadecimal)
12 Watchdog time-out action Yes No 01 (hexadecimal)
13 Produced connection
path length
Yes No 00 (hexadecimal)
14 Produced connection
path
Ye s No
15 Consumed connection
path
Yes No 00 (hexadecimal)
Service DeviceNet service Parameter option
05 Reset None
0E Get_Attribute_Single None
10 Set_Attribute_Single None
