Omron K3HB-R User Manual

10-6
Mounted Objects Section 8-2
Additional Informa-
tion for DeviceNet
1. Produced Connection Paths
IN Area 1: 20_04_24_64_30_03
IN Area 2: 20_04_24_65_30_03
2. Consumed Connection Paths
OUT Area: 20_04_24_6E_30_03
Object
instance 2
Section Information Maximum number of instances
Instance type Polled I/O 1
Production
trigger
Cyclic
Transport type Server
Transport
class
2
Attribute ID Contents Get (read) Set (write) Value
1 State Yes No
2 Instance type Yes No 01 (hexadecimal)
3 Transport class trigger Yes No 82 (hexadecimal)
4 Produced connection ID Yes No
5 Consumed connection ID Yes No
6 Initial comm. characteris-
tics
Yes No 01 (hexadecimal)
7 Produced connection size Yes No
8 Consumed connection
size
Ye s No
9 Expected packet rate Yes Yes
12 Watchdog time-out action Yes No 00 (hexadecimal)
13 Produced connection
path length
Yes No 06 (hexadecimal)
14 Produced connection
path
Yes No See note 1.
15 Consumed connection
path length
06 (hexadecimal)
16 Consumed connection
path
Yes No See note 2.
17 Production inhibit time Yes No 0000 (hexadecimal)
Service DeviceNet service Parameter option
05 Reset None
0E Get_Attribute_Single None
10 Set_Attribute_Single None
