Omron K3HB-R User Manual

2-4
List of Settings Section 2
List of
Settings
Initial Setting Level
Variable
type
Address Parameter
name
Char-
acter
Monitor/Setting range Character Default
setting
Decimal
point
Unit Model
XVSH
C4 0000 Calculation cal H’00000000: A(0), H’00000001:B(1),
H’00000002:K-A(2), H’00000003:
A+B(3),
H’00000004: A-B(4), H’00000005: K
−
(A+B)(5), H’00000000: B/A×10000(6),
H’00000007: (B/A
−1) × 10000(7)
0, 1, 2, 3, 4,
5, 6, 7
0 --- --- x x x
0001 Input type A in-ta X(VD):
H’00000000:
±199.99 V(0),
H’00000001:
±19.999 V(1),
H’00000002:
±1.9999 V(2),
H’00000003: 1.0000 to 5.0000 V(3)
X(AD):
H’00000000:
±199.99 mA(0),
H’00000001:
±19.999 mA(1),
H’00000002:
±1.9999 mA(2),
H’00000003: 4.000 to 20.000 mA(3)
X(VA):
H’00000000: 0.0 to 400.0 V(0),
H’00000001: 0.00 to 199.99 V(1),
H’00000002: 0.000 o 19.999 V(2),
H’00000003: 0.0000 to 1.9999 V(3)
X(AA):
H’00000000: 0.000 to 10.000 A(0),
H’00000001: 0.0000 to 1.9999 A(1),
H’00000002: 0.00 to 199.99 mA(2),
H’00000003: 0.000 to 19.999 m(3)
V:
H’00000000: 0.00 to 199.99 mV(0),
H’00000001: 0.000 to 19.999 mV(1),
H’00000002:
±100.00 mV(2),
H’00000003:
±199.99 mV(3)
S:
H’00000000: 0 to 20 mA(0)
H’00000001: 4 to 20 mA(1),
H’00000002: 0 to 5 V(2),
H’00000003: 1 to 5 V(3),
H’00000004:
±5 V(4),
H’00000005:
±10 V(5)
H:
H’00000000: 0-Pt100(0), H’00000001:
1-Pt100(1), H’00000002: 2-K(2),
H’00000003: 3-K(3), H’00000004: 4-
J(4), H’00000005: 5-J(5), H’00000006:
6-T(6), H’00000007: 7-E(7),
H’00000008: 8-L(8), H’00000009: 9-
V(9), H’0000000A: 10-N(10),
H’0000000B: 11-R(11), H’0000000C:
12-S(12), H’0000000D: 13-B(13),
H’0000000E: 14-W(14)
X(VD):
a vd, b vd,
c vd, d vd
X(AD):
a ad, b ad,
c ad, d ad
X(VA):
a va, b va,
c va, d va
X(AA):
a aa, b aa,
c aa, d aa
V:
a lc, b lc,
c lc, d lc
S:
0-20, 4-20,
0-5, 1-5, 5,
10
H:
0-pt, 1-pt,
2-k, 3-k, 4-
j, 5-j, 6-t,
7-e, 8-l, 9-
u, 10-n, 11-
r, 12-s, 13-
b, 14-w
X(VD): a vd
X(AD): a ad
X(VA): a va
X(AA): a aa
V: a lc
S: 4 to 20
H: 2-k
--- ---
0002 Power sup-
ply fre-
quency
fre H’00000000: 50(0), H’00000001: 60(1) 50, 60 50 --- Hz x
0003 Scaling
input value
A1
inp
. a1 H’FFFFB1E1 to H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
X (VD):
:99 . 99
X (AD):
:99 . 99
X (VA): 0
. 0
X (AA):
0 . 000
V: 0
. 00
S: 4
. 000
Accord-
ing to the
input type
Accord-
ing to
the
input
type
x
0004 Scaling dis-
play value
A1
dsp
. a1 H’FFFFB1E1 to H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
X (VD):
:9999
X (AD):
:9999
X (VA): 0
X (AA): 0
V: 0
S: 4000
--- --- x
