Omron K3HB-R User Manual

2-3
List of Settings Section 2
List of
Settings
Communications Monitoring Settings
Note The values beginning with H’ in the Monitor/Setting range column are used when setting or monitoring
data via communications.
Protect Level
Note The values beginning with H’ in the Monitor/Setting range column are used when setting or monitoring
data via communications.
RUN Level
Note The values beginning with H’ in the Monitor/Setting range column are used when setting or monitoring
data via communications.
Variable
type
Address Setting data Character Monitor/Setting range Character Default
setting
Decimal
point
Unit Model
XVSH
C0 0000 Version --- --- --- --- --- ---
0001 Status --- --- --- --- --- ---
0002 Measurement
value
--- H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
--- --- --- ---
0003 MAX value --- H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
--- --- --- ---
0004 MIN value --- H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
--- --- --- ---
Variable
type
Address Parameter
name
Character Monitor/Setting range Character Default
setting
Decimal
point
Unit Model
XVSH
C1 0000 RUN/Adjust-
ment protect
run.pt H’00000000 to
H’00000002: (0 to 2)
0 to 20 --- ---
0001 Setting level
protect
set.pt H’00000000 to
H’00000002: (0 to 2)
0 to 21 --- ---
0002 Setting change
protect
wt.pt H’00000000: OFF(0)
H’00000001: ON(1)
off, on off --- ---
0003 Forced zero
protect
zr.pt H’00000000: OFF(0)
H’00000001: ON(1)
off, on off --- --- x
0004 MAX/MIN pro-
tect
mm.pt H’00000000 to
H’00000002: (0 to 2)
0 to 20 --- ---
Variable
type
Address Parameter
name
Character Monitor/Setting range Character Default
setting
Decimal
point
Unit Model
XVSH
C2 0000 Comparative
set value HH
--- H’FFFFB1E1 to H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
99999 According to
the decimal
position set-
ting
---
0001 Comparative
set value H
--- H’FFFFB1E1 to H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
99999 According to
the decimal
position set-
ting
---
0002 Comparative
set value L
--- H’FFFFB1E1 to H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
:9999 According to
the decimal
position set-
ting
---
0003 Comparative
set value LL
--- H’FFFFB1E1 to H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
:9999 According to
the decimal
position set-
ting
---
