Omron K3HB-R User Manual

2-6
List of Settings Section 2
List of
Settings
Input Adjustment Level
Note The values beginning with H’ in the Monitor/Setting range column are used when setting or monitoring
data via communications.
Variable
type
Address Parameter
name
Character Monitor/Setting
range
Character Default
setting
Decimal
point
Unit model
XVSH
C5 0000 Timing hold tmg-h H’00000000:
Normal(0),
H’00000001:
sampling(1),
H’00000002: peak(2),
H’00000003:
bottom(3),
H’00000004:
peak to peak(4)
nomal, s-h,
p-h, b-h,
p-p
nomal --- ---
0001 ON timing
delay
on-t H’00000000 to
H’00001387:
(0 to 4999)
0 to 4999 0 --- S: ms
Others:
100 ms
0002 OFF timing
delay
off-t H’00000000 to
H’00001387:
(0 to 4999)
0 to 4999 0 --- S: ms
Others:
100 ms
0003 Zero limit z-lim H’00000000: OFF(0)
H’00000001: ON(1)
off, on off --- ---
0004 Zero limit value lim-p H’00000000 to
H’00000063: (0 to 99)
0 to 99 0 According to
the decimal
position set-
ting
---
0005 Step value step H’00000000: OFF(0),
H’00000001: 2(1),
H’00000002: 5(2),
H’00000003: 10(3)
off, 2, 5, 10 off --- digit
0006 Average type avg-t H’00000000: Simple
average(0),
H’00000001: move
average(1)
smpl, move smpl --- ---
0007 Averaging
times
avg-n H’00000000:
1(0)/H’00000001: 2(1)/
H’00000002: 4(2)/
H’00000003: 8(3)/
H’00000004:16(4)/
H’00000005:32(5)/
H’00000006: 64(6)/
H’00000007: 128(7)/
H’000000008: 256(8)/
H’000000009: 512(9)/
H’00000000A:
1024(10) times
1, 2, 4, 8, 16,
32, 64, 128,
256, 512,
1024
1 --- ---
0008 Input shift input
1
isi
. 1 H’FFFFB1E1 to
H’0001869F
(−19,999 to 99,999)
:9999 to
99999
-200
. 0 According to
the input type
--- x x x
0009 Input shift
value 1
iss
. 1 H’FFFFB1E1 to
H’0001869F
(−19,999 to 99,999)
:99
. 99 to
999
. 99
0
. 00 2---xxx
000A Input shift input
2
isi
. 2 H’FFFFB1E1 to
H’0001869F
(−19,999 to 99,999)
:9999 to
99999
1300
. 0 According to
the input type
--- x x x
000B Input shift
value 2
iss
. 2 H’FFFFB1E1 to
H’0001869F
(−199.99 to 99.999)
:99
. 99 to
99
. 999
0
. 00 2---xxx
0010 Power interrup-
tion memory
memo H’00000000: OFF(0),
H’00000001: ON(1)
off, on off --- ---
