List of Settings Section 2
List of
Settings
Note The values beginning with H’ in the Monitor/Setting range column are used when setting or monitoring
data via communications.
Linear Output Level
Note The values beginning with H’ in the Monitor/Setting range column are used when setting or monitoring
data via communications.
C8 0016 Compara-
tive set
value 5 L
sv5.l H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
:9999 According to
the decimal
position set-
ting
---
0017 Compara-
tive set
value 5 LL
sv5.ll H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
:9999 According to
the decimal
position set-
ting
---
0018 Compara-
tive set
value 6 HH
sv6.hh H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
99999 According to
the decimal
position set-
ting
---
0019 Compara-
tive set
value 6 H
sv6.h H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
99999 According to
the decimal
position set-
ting
---
001A Compara-
tive set
value 6 L
sv6.l H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
:9999 According to
the decimal
position set-
ting
---
001B Compara-
tive set
value 6 LL
sv6.ll H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
:9999 According to
the decimal
position set-
ting
---
001C Compara-
tive set
value 7 HH
sv7.hh H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
99999 According to
the decimal
position set-
ting
---
001D Compara-
tive set
value 7 H
sv7.h H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
99999 According to
the decimal
position set-
ting
---
001E Compara-
tive set
value 7 L
sv7.l H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
:9999 According to
the decimal
position set-
ting
---
001F Compara-
tive set
value 7 LL
sv7.ll H’FFFFB1E1 to
H’0001869F
(
−19,999 to 99,999)
:9999 to
99999
:9999 According to
the decimal
position set-
ting
---
Variable
type
Address Parameter
name
Character Monitor/Setting range Character Default
setting
Decimal
point
Unit Model
XVSH
C9 0000 Linear cur-
rent type
lset.c H’00000000: 0 to 20 mA(0),
H’00000001: 4 to 20 mA(1)
0-20, 4-20 4-20 --- ---
0001 Linear volt-
age type
lset.v H’00000000: 0 to 5 V(0),
H’00000001: 1 to 5 V(1),
H’00000002: 0 to 10 V(2)
0-5, 1-5,
0-10
1-5 --- ---
0002 Linear out-
put upper
limit
lset.h H’FFFFB1E1 to
H’0001869F (
−19,999 to
99,999)
:9999 to
99999
X (VD):
19999
X (AD):
19999
X (VA):
4000
X (AA):
10000
V: 19999
S: 99999
H: 1300
. 0
According to
the decimal
position set-
ting
---
0003 Linear out-
put lower
limit
lset.l H’FFFFB1E1 to
H’0001869F (
−19,999 to
99,999)
:9999 to
99999
X (VD):
:9999
X (AD):
:9999
X (VA): 0
X (AA): 0
V: 0
S: :9999
H: -200
. 0
According to
the decimal
position set-
ting
---
Variable
type
Address Parameter
name
Character Monitor/Setting range Character Default
setting
Decimal
point
Unit Model
XVSH
