Omron K3HB-R User Manual

2-10
List of Settings Section 2
List of
Settings
Communications Setting Level
Note The values beginning with H’ in the Monitor/Setting range column are used when setting or monitoring
data via communications.
Advanced Function Setting Level
Note (1) The values beginning with H’ in the Monitor/Setting range column are used when setting or monitoring
data via communications.
(2) If the event connector is provided as a standard feature or an event connector is added, use EV for
the “bank selection” setting.
Variable
type
Address Parameter
name
Character Monitor/Setting range Character Default
setting
Decimal
point
Unit Model
XVSH
CA 0000 Unit No. u-no H’00000000 to
H’00000063: (0 to 99)
0 to 99 1 --- ---
0001 Baud rate bps H’00000000: 9.6(0),
H’00000001: 19.2(1),
H’00000002: 38.4(2)
9
. 6, 19 . 2,
38
. 4
9
. 6 --- kbps
0002 Data length len H’00000000: 7(0),
H’00000001: 8(1)
7, 87 --- bit
0003 Stop bit
length
sbit H’00000000: 1(0),
H’00000001: 2(1)
1, 22 --- bit
0004 Parity prty H’00000000: None (0),
H’00000001: Even (1),
H’00000002: Odd (2)
none, even,
odd
even --- ---
0005 Send wait
time
sdwt H’00000000 to
H’00000063 (0 to 99)
0 to 99 20 --- ms
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal
point
Unit Model
XVSH
CB 0000 PASS-output
change
pass H’00000000: LL(0), H’00000001:
L(1), H’00000002: PASS(2),
H’00000003: H(3), H’00000004:
HH(4), H’00000005: ERR(5)
ll, l, pass,
h, hh, err
pass --- ---
0001 Hysteresis hys H’00000000 to
H’0000270F: (0 to 9,999)
0 to 9999 1 According to
the decimal
position set-
ting
---
0002 Output OFF
delay
off-d H’00000000 to
H’000007CF (0 to 1,999)
0 to 1999 0 --- S: ms
Others:
100 ms
0003 Shot output shot H’00000000 to
H’000007CF (0 to 1,999)
0 to 1999 0 --- S: ms
Others:
100 ms
0004 Output logic out-n H’00000000: Close in alarm(0),
H’00000001: Open in alarm(1)
n-o, n-c n-o --- ---
0005 Output
refresh stop
o-stp H’00000000: OFF(0), H’00000001:
OUT(1), H’00000002: ALL(2)
off, out, all off --- ---
0006 Tare zero t-zr H’00000000: OFF(0)
H’00000001: ON(1)
off, on off --- --- x
0007 Zero trim-
ming
z-trm H’00000000: OFF(0)
H’00000001: ON(1)
off, on off --- --- x
0008 Previous
average
value com-
parison
hp-f H’00000000: OFF(0)
H’00000001: ON(1)
off, on off --- ---
0009 Bank selec-
tion
bnk-c H’00000000: OFF(0), H’00000001:
KEY(1), H’00000002: EV(2)
off, key, ev off
(See note.)
--- ---
000A Startup com-
pensation
timer
s-tmr H’00000000 to
H’0000270F: (0 to 99.9)
0 . 0 to 99 . 90 . 0 1s
000B Input error
enable
s.err H’00000000: Disable(0),
H’00000001: overflow(1),
H’00000002: input error(2)
off, over,
s.err
s.err --- ---
000C Standby
sequence
stdby H’00000000: OFF(0)
H’00000001: ON(1)
off, on off --- ---
000D Cold junction
compensat-
ing circuit
cjc H’00000000: OFF(0)
H’00000001: ON(1)
off, on on --- --- x x x
