Omron K3HB-R User Manual

2-15
List of Settings Section 2
List of
Settings
Comparative Set Value Level
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
C8 0000 Comparative set
value 0HH
s?0. hh H’FFFFB1E1 to H’0001869F: −19999 to 99999
(Time limit is OFF. Lower limit of P is 0.)
H’00000000 to H’0001869F: 0 to 99999
(Time unit is min.)
H’00000000 to H’000176D7: 0.00.00 to 9.59.59
(Time unit is hr:min:s.)
H’00000000 to H’0001850F: 00.00.0 to 99.59.9
(Time unit is min:s:ms.)
:9999 to 99999
0. 00. 00 to 99999
0. 00. 00 to
9. 59. 59
0. 00. 00 to
99. 59. 9
99999 According to the
decimal position
setting. The time
unit, however, is
indicated as
*.**.** for
hr:min:s and
as **.**.* for
min:s:ms.
---
0001
Comparative set
value 0H
s?0. h Same as above Same as above 99999 Same as above ---
0002
Comparative set
value 0L
s?0. l Same as above Same as above R: :9999
P: 0
Same as above ---
0003
Comparative set
value 0LL
s?0. ll Same as above Same as above R: :9999
P: 0
Same as above ---
0004 Comparative set
value 1HH
s?1. hh Same as above Same as above 99999 Same as above ---
0005
Comparative set
value 1H
s?1. h Same as above Same as above 99999 Same as above ---
0006
Comparative set
value 1L
s?1. l Same as above Same as above R: :9999
P: 0
Same as above ---
0007
Comparative set
value 1LL
s?1. ll Same as above Same as above R: :9999
P: 0
Same as above ---
0008 Comparative set
value 2HH
s?2. hh Same as above Same as above 99999 Same as above ---
0009
Comparative set
value 2H
s?2. h Same as above Same as above 99999 Same as above ---
000A
Comparative set
value 2L
s?2. l Same as above Same as above R: :9999
P: 0
Same as above ---
000B
Comparative set
value 2LL
s?2. ll Same as above Same as above R: :9999
P: 0
Same as above ---
000C Comparative set
value 3HH
s?3. hh Same as above Same as above 99999 Same as above ---
000D
Comparative set
value 3H
s?3. h Same as above Same as above 99999 Same as above ---
000E
Comparative set
value 3L
s?3. l Same as above Same as above R: :9999
P: 0
Same as above ---
000F
Comparative set
value 3LL
s?3. ll Same as above Same as above R: :9999
P: 0
Same as above ---
0010 Comparative set
value 4HH
s?4. hh Same as above Same as above 99999 Same as above ---
0011
Comparative set
value 4H
s?4. h Same as above Same as above 99999 Same as above ---
0012
Comparative set
value 4L
s?4. l Same as above Same as above R: :9999
P: 0
Same as above ---
0013
Comparative set
value 4LL
s?4. ll Same as above Same as above R: :9999
P: 0
Same as above ---
0014 Comparative set
value 5HH
s?5. hh Same as above Same as above 99999 Same as above ---
0015
Comparative set
value 5H
s?5. h Same as above Same as above 99999 Same as above ---
0016
Comparative set
value 5L
s?5. l Same as above Same as above R: :9999
P: 0
Same as above ---
0017
Comparative set
value 5LL
s?5. ll Same as above Same as above R: :9999
P: 0
Same as above ---
0018 Comparative set
value 6HH
s?6. hh Same as above Same as above 99999 Same as above ---
0019
Comparative set
value 6H
s?6. h Same as above Same as above 99999 Same as above ---
001A
Comparative set
value 6L
s?6. l Same as above Same as above R: :9999
P: 0
Same as above ---
001B
Comparative set
value 6LL
s?6. ll Same as above Same as above R: :9999
P: 0
Same as above ---
001C Comparative set
value 7HH
s?7. hh Same as above Same as above 99999 Same as above ---
001D
Comparative set
value 7H
s?7. h Same as above Same as above 99999 Same as above ---
001E
Comparative set
value 7L
s?7. l Same as above Same as above R: :9999
P: 0
Same as above ---
001F
Comparative set
value 7LL
s?7. ll Same as above Same as above R: :9999
P: 0
Same as above ---
