Omron K3HB-R User Manual

2-17
List of Settings Section 2
List of
Settings
K3HB-C
Communications Monitoring Settings
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
Protect Level
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
RUN Level
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
C0
0000
Version --- --- --- --- --- ---
0001 Status --- --- --- --- --- ---
0002 Measurement
value
--- H’FFFFB1E1 to H’0001869F: (−19999 to 99999) --- --- --- ---
0003 Max. value --- H’FFFFB1E1 to H’0001869F: (−19999 to 99999) --- --- --- ---
0004 Min. value --- H’FFFFB1E1 to H’0001869F: (−19999 to 99999) --- --- --- ---
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
C1 0000 RUN/adjustment
protect
run. pt H’00000000 to H’00000002: (0 to 2) 0 to 20--- ---
0001 Setting level
protect
set. pt H’00000000 to H’00000002: (0 to 2) 0 to 21--- ---
0002 Setting change
protect
wt.
pt H’00000000: OFF (0)
H’00000001: ON (1)
off, on off --- ---
0003 Max/Min protect mm.
pt H’00000000 to H’00000002: (0 to 2) 0 to 20--- ---
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
C2 0000 Measurement
value/comparative
set value 5
--- H’FFFFB1E1 to H’0001869F: (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0001 Measurement
value/comparativ
e set value 4
--- H’FFFFB1E1 to H’0001869F: (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0004 Measurement
value/comparativ
e set value 3
--- H’FFFFB1E1 to H’0001869F: (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0002 Measurement
value/comparativ
e set value 2
--- H’FFFFB1E1 to H’0001869F: (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
0003 Measurement
value/comparativ
e set value 1
--- H’FFFFB1E1 to H’0001869F: (−19999 to 99999) :9999 to 99999 99999 According to the
decimal position
setting.
---
