■ Input Ranges
Platinum-resistance Thermometer/Thermocouple
The range shown in dark shading indicates the factory setting.
Celsius/Fahrenheit Correlation Values and Setting/Specified Ranges
Input type Platinum-
resistance
thermometer
Thermocouple
Name Pt100 K J T E L U N R S B W
(W/Re
5-26)
Connected
terminals
Te m -
pera-
ture
range
(
°C)
2300
1800
1300
900
800
700
600
400
200
100
0
−100
−200
2300.0
1700.0 1700.0 1800.0
1300.0 1300.0
850.0 850.0 850.0
500.0 600.0
400.0 400.0 400.0
150.00
100.0
0.0 0.0 0.0 0.0
−20.0 −100.0 −20.0 −100.0
−200.0
−150.00
−200.0 −200.0 −200.0 −200.0
Setting code 0-pt 1-pt 2-k 3-k 4-j 5-j 6-t 7-e 8-l 9-u 10-n 11-r 12-s 13-b 14-w
Minimum
setting unit
(comparative
set value)
0.1
°C0.01°C0.1°C
Input type Setting range Indication range
°C °F °C °F
Pt100 (1)
−200.0 to 850.0 −300.0 to 1500.0 −305.0 to 955.0 −480.0 to 1680.0
Pt100 (2)
−150.00 to 150.00 −199.99 to 300.00 −180.00 to 180.00 −199.99 to 350.00
K (1)
−200.0 to 1300.0 −300.0 to 2300.0 −350.0 to 1450.0 −560.0 to 2560.0
K (2)
−20.0 to 500.0 0.0 to 900.0 −72.0 to 552.0 −90.0 to 990.0
J (1)
−100.0 to 850.0 −100.0 to 1500.0 −195.0 to 945.0 −260.0 to 1660.0
J (2)
−20.0 to 400.0 0.0 to 750.0 −62.0 to 442.0 −75.0 to 825.0
T
−200.0 to 400.0 −300.0 to 700.0 −260.0 to 460.0 −400.0 to 800.0
E
0.0 to 600.0 0.0 to 1100.0 −60.0 to 660.0 −110.0 to 1210.0
L
−100.0 to 850.0 −100.0 to 1500.0 −195.0 to 945.0 −260.0 to 1660.0
U
−200.0 to 400.0 −300.0 to 700.0 −260.0 to 460.0 −400.0 to 800.0
N
−200.0 to 1300.0 −300.0 to 2300.0 −350.0 to 1450.0 −560.0 to 2560.0
R
0.0 to 1700.0 0.0 to 3000.0 −170.0 to 1870.0 −300.0 to 3300.0
S
0.0 to 1700.0 0.0 to 3000.0 −170.0 to 1870.0 −300.0 to 3300.0
B
100.0 to 1800.0 300.0 to 3200.0 −70.0 to 1970.0 10.0 to 3490.0
W
0.0 to 2300.0 0.0 to 4100.0 −230.0 to 2530.0 −410.0 to 4510.0
E4 E5 E6 E5 E6
