18 Linear Sensor Indicator K3HB-S
■ Characteristics
■ Input Ranges (Measurement Ranges and Accuracy)
Note: The accuracy is for an ambient temperature of 23±5°C.
Display range −19,999 to 99,999
Sampling period One input: 0.5 ms; Two inputs: 1.0 ms
Comparative out-
put response
times (transistor
outputs)
One input OFF to ON: 1 ms max., ON to OFF: 1.5 ms max.
Two inputs OFF to ON: 2 ms max., ON to OFF: 2.5 ms max.
Linear output re-
sponse time
One input 51 ms max.
Two inputs 52 ms max.
Insulation resistance 20 M
Ω min. (at 500 VDC)
Dielectric strength 2,300 VAC for 1 min between external terminals and case
Noise immunity 100 to 240 VAC models:
±1,500 V at power supply terminals in normal or common mode
(waveform with 1-ns rising edge and pulse width of 1
µs/100 ns)
24 VAC/VDC models:
±1,500 V at power supply terminals in normal or common mode
(waveform with 1-ns rising edge and pulse width of 1
µs/100 ns)
Vibration resistance
Frequency: 10 to 55 Hz; Acceleration: 50 m/s
2
, 10 sweeps of 5 min each in X, Y, and Z directions
Shock resistance
150 m/s
2
(100 m/s
2
for relay outputs) 3 times each in 3 axes, 6 directions
Weight Approx. 300 g (Base Unit only)
Degree of protec-
tion
Front panel Conforms to NEMA 4X for indoor use (equivalent to IP66)
Rear case IP20
Terminals IP00 + finger protection (VDE0106/100)
Memory protection EEPROM (non-volatile memory)
Number of rewrites: 100,000
Applicable standards UL61010C-1, CSA C22.2 No. 1010.1(evaluated by UL)
EN61010-1 (IEC61010-1): Pollution degree 2/Overvoltage category II
EN61326: 1997, A1: 1998, A2: 2001
EMC EMI: EN61326+A1 industrial applications
Electromagnetic radiation interference
CISPR 11 Group 1, Class A: CISPRL16-1/-2
Terminal interference voltage
CISPR 11 Group 1, Class A: CISPRL16-1/-2
EMS: EN61326+A1 industrial applications
Electrostatic Discharge Immunity
EN61000-4-2: 4 kV (contact), 8 kV (in air)
Radiated Electromagnetic Field Immunity
EN61000-4-3: 10 V/m 1 kHz sine wave amplitude modulation (80 MHz to 1 GHz)
Electrical Fast Transient/Burst Immunity
EN61000-4-4: 2 kV (power line), 1 kV (I/O signal line)
Surge Immunity
EN61000-4-5: 1 kV with line (power line), 2 kV with ground (power line)
Conducted Disturbance Immunity
EN61000-4-6: 3 V (0.15 to 80 MHz)
Voltage Dips and Interruptions Immunity
EN61000-4-11: 0.5 cycle, 0
°/180°, 100% (rated voltage)
Input Input type Measurement range Indication range Input
impedance
Accuracy
(at 23
±5°C)
Maximum
absolute rated
input
K3HB-SSD
DC voltage/current
input
0 to 20 mA 0.000 to 20.000 mA
−2.000 to 22.000 mA 120 Ω max. One input:
±0.1% F.S.
±1 digit max.
Two inputs:
±0.2% F.S.
±1 digit max.
±31 mA
4 to 20 mA 4.000 to 20.000 mA 2.000 to 22.000 mA
0 to 5 V 0.000 to 5.000 V
−0.500 to 5.500 mA 1 MΩ min. ±10 V
1 to 5 V 1.000 to 5.000 V 0.500 to 5.500 V
±5 V ±5.000 V ± 5.500 V
±10 V ±10.000 V ± 11.000 V ±14.5 V
