Omron MC-510 Gentle Temp User Manual

TITLE
11
MEASUREMENT IN "DIRECT MODE"
3
Insert the probe into the ear.
When it beeps,
you can start the
measurement.
This is the measurement mode recommended when the
direction of the eardrum is difficult to find such as when
measuring the temperature of an infant.
Prepare for measurement in accordance with
Sections
1 and 2 in pages 6-7.
Hold the main unit with your fingers as shown
below. Insert the probe in the ear as far as it goes in
the direction of the eardrum.
4
Shift the probe right and left.
The unit automatically detects the temperature of the
eardrum in 10 seconds maximum.
Beep!
Asia EN-02-20[MC-510]-9 10/1/03 11:59 AM Page 11

Omron MC-510 Gentle Temp Specifications

Power

voltage	3 VDC
power consumption	0.05 W
battery life	Measurements of approx. 2000 times

Temperature Measurement

temperature indication	In 3 digits in +°C or 4 digits in +°F
precision	±0.3°C (±0.5°F) or ±0.2°C (±0.4°F)
measurement range	34 to 42.2°C (93.2 to 108°F)

Operating Environment

operating temperature	10 to 40°C (50 to 104°F)
operating relative humidity	30 to 85%
storage temperature	-20 to 60°C (-4 to 140°F)
storage relative humidity	10 to 95%

Weight and Dimensions

weight	Approx. 50g
external dimensions	Approx. 45 (W) x 94 (H) x 58 (D)
