7 Connecting to LSIS PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
7-4 Supported Registers
7
LS XGT CPU Direct
Note Address format description: D: decimal, O: octonary, H: hexadecimal.
LS XEC Cnet
Device Bit Address Word Address Format
File Relay R_bit 0.0-10239.F ------ DDDDD.H
Data Relay D_bit 0.0-10239.F ------ DDDDD.H
Communication Relay N_bit 0.0-5119.F ------ DDDD.H
Link Relay L_bit 0.0-2047.F ------ DDDD.H
Index Relay Z_bit 0.0-127.F ------ DDD.H
ZR_bit 0.0-10239.F ------ DDDDD.H
Counter Contact Relay C_bit 0-1023 ------ DDDD
Timer Contact Relay T_bit 0-1023 ------ DDDD
Special Relay F_bit 0.0-1023.F ------ DDDD.H
Keep Relay K_bit 0.0-4095.F ------ DDDD.H
Auxiliary Relay M_bit 0.0-1023.F ------ DDDD.H
I/O Relay P_bit 0.0-1023.F ------ DDDD.H
File Register ------ R 0-10239 DDDDD
Data Register ------ D 0-10239 DDDDD
Communication Register ------ N 0-5119 DDDD
Link Register ------ L 0-2047 DDDD
Step Control Register ------ S 0-127 DDD
Index Register ------ Z 0-127 DDD
------ ZR 0-10239 DDDDD
Counter Set Value ------ C_ SV 0-1023 DDDD
Timer Set Value ------ T_ SV 0-1023 DDDD
Counter Current Value ------ C_ CV 0-1023 DDDD
Timer Current Value ------ T_ CV 0-1023 DDDD
Special Register ------ F 0-1023 DDDD
Keep Register ------ K 0-4095 DDDD
Auxiliary Register ------ M 0-1023 DDDD
I/O Register ------ P 0-1023 DDDD
Device Bit Address Word Address Format
A_bit 0-131071 ------ DDDDDD
Special Relay F_bit 0-16383 ------ DDDDD
W_bit 0-163839 ------ DDDDDD
File Relay R_bit 0-163839 ------ DDDDDD
Special module Relay U_bit 0-8191 ------ DDDD
Keep Relay K_bit 0-65535 ------ DDDDD
Link Relay L_bit 0-32767 ------ DDDDD
Auxiliary Relay M_bit 0-65535 ------ DDDDD
Communication Relay N_bit 0-163839 ------ DDDDDD
Output Relay Q_bit 0-16383 ------ DDDDD
Input Relay I_bit 0-16383 ------ DDDDD
------ A 0-8191 DDDD
Special Register ------ F 0-1023 DDDD
------ W 0-10239 DDDDD
