7 Connecting to LSIS PLCs
7-12
NB-series Programmable Terminals Host Connection Manual (V108)
7-4 Supported Registers
K120S K7M-DR10UE
Note For bit registers, if the address in PLC is F01, then the address in PT should be set to F0.1; and if the
address in PLC is F2A, then the address in PT should be set to F2.A, and the others can be deduced
according to this rule.
LS XGT Cnet
Note T_bit and C_bit registers do not support the commuinication system which requires serial addresses simulta-
neously.
Address format description: D: decimal, O: octonary, H: hexadecimal.
Device Bit Address Word Address Format Notes
I/O Relay P 0.0-63.f ------ DD.H
Auxiliary Relay M 0.0-191.f ------ DDD.H
Link Relay L 0.0-63.f ------ DD.H
Keep Relay K 0.0-31.f ------ DD.H
Special Relay F 0.0-31.f DD.H
Timer ------ T 0-255 DDD
Counter ------ C 0-255 DDD
Data Register D 0-4999 DDDD
Device Bit Address Word Address Format
File Relay R_bit 0.0-10239.F DDDDD.H
Data Relay D_bit 0.0-10239.F DDDDD.H
Communication Relay N_bit 0.0-5119.F DDDD.H
Link Relay L_bit 0.0-2047.F DDDD.H
Index Relay Z_bit 0.0-127.F ------ DDD.H
Counter Contact Relay C_bit 0-1023 ------ DDDD
Timer Contact Relay T_bit 0-1023 ------ DDDD
Special Relay F_bit 0.0-1023.F ------ DDDD.H
Keep Relay K_bit 0.0-4095.F ------ DDDD.H
Auxiliary Relay M_bit 0.0-1023.F ------ DDDD.H
I/O Relay P_bit 0.0-1023.F ------ DDDD.H
File Register ------ R_word 0-10239 DDDDD
Data Register ------ D_ word 0-10239 DDDDD
Communication Register ------ N_ word 0-5119 DDDD
Link Register ------ L_ word 0-2047 DDDD
Step Control Register S_ word 0-127 DDD
Index Register Z_ word 0-127 DDD
Counter ------ C_ word 0-1023 DDDD
Timer ------ T_ word 0-1023 DDDD
Special Register ------ F_ word 0-1023 DDDD
Keep Register ------ K_ word 0-4095 DDDD
Auxiliary Register ------ M_ word 0-1023 DDDD
I/O Register ------ P_ word 0-1023 DDDD
