3 Connecting to Mitsubishi PLCs
3-14
NB-series Programmable Terminals Host Connection Manual (V108)
RS232 Communication
Note There is no need to set PLC baud rate that will automatically vary with the baud rate set by PT.
PT default communication parameters: 115200bps (Baud Rate), 8 (Data Bit), odd (Parity Check), 1
(Stop Bit) and 0 (PLC Station No.) (Multiple Station No. is not supported.)
RS232 Communication
Note There is no need to set PLC baud rate that will automatically vary with the baud rate set by PT.
3-3-6 When Using Mitsubishi Q06H Communication Protocol
PT Settings
To Next Page
