3 Connecting to Mitsubishi PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
3-3 Communication Setting
3
3-3-7 When Using Mitsubishi Q_QnA (Link Port) Communication Protocol
PT default communication parameters: 9600bps (Baud Rate), 8 (Data Bit), odd (Parity Check), 1 (Stop
Bit) and 0 (PLC Station No.)
RS232 Communication
RS422 Communication
3-3-7 When Using Mitsubishi Q_QnA (Link Port) Communication
Protocol
PT Settings
