Omron NJ Series Network Connection Guide

7. Connection Procedure
7.5.2. Transferring the Tag Data Link Parameters
Connect the Network Configurator online and transfer the tag data link parameters to the
Controller.
Precautions for Correct Use
Please confirm that the LAN cable is connected before performing the following procedures.
When it is not connected, turn OFF the power supply to each device and then connect the
LAN cable.
1
Select Select Interface - NJ
Series USB Port from the
Option Menu.
2
Select Connect from the
Network Menu.
3
The Select Connect Network
Port Dialog Box is displayed.
Select TCP:2 and click the OK
Button.
34
