Omron NJ Series

9. Appendix 1 Detailed Settings of the Tag Data Links
47
Allocation of EIPOutput.CommonControlFlag.W variable
Offset
(word)
15 14 13 … 2 1 0
+0 15 14 13 … 2 1 0
+1 31 30 29 … 18 17 16
Bits 31 to 0: EIPOutput.CommonControlFlag.W uses DWORD data from
offset + 2 words.
*5: Details on allocation of sensor head 1 control signal
Allocation of EIPOutput.SensorHead1ControlFlag.F variable
Offset
(word)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
+2
LIGHT
OFF
RESET1
TIMING1
+3
ZEROCL
R_T4
ZEROCL
R_T3
ZEROCL
R_T2
ZEROCL
R_T1
ZERO1_
T4
ZERO1_
T3
ZERO1_
T2
ZERO1_
T1
TIMING1: Timing bit: Turns ON when the Controller instructs start of hold
sampling to the displacement sensor.
RESET1: Reset bit: Turns ON when the Controller resets judgment
processing and output of the displacement sensor. If the hold
function is used, the state before the hold function was set will be
restored.
LIGHTOFF1: Light metering OFF bit: Turns ON when the Controller instructs
logical beam OFF to the displacement sensor.
ZERO1_T1 to 4: Zero reset execution bit: Turns ON when the Controller
instructs execution of zero reset of TASK1 to 4 to the
displacement sensor.
ZEROCLR1_T1 to 4: Zero reset cancel bit: Turns ON when the Controller
instructs zero reset cancel of TASK1 to 4 to the displacement
sensor.
Allocation of EIPOutput.SensorHead1ControlFlag.W variable
Offset
(word)
15 14 13 … 2 1 0
+2 15 14 13 … 2 1 0
+3 31 30 29 … 18 17 16
Bits 31 to 0: EIPOutput.SensorHead1ControlFlag.W uses DWORD data from
offset + 2 words.
*6: Details on allocation of sensor head 2 control signal (reserved)
Allocation of EIPOutput.SensorHead2ControlReserve.F variable
Offset
(word)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
+4
+5
