Omron NJ Series Network Connection Guide

10. Appendix 2 Setting the Tag Data Links Using the Software
10.4.4. Transferring the Tag Data Link Parameters
Transfer the tag data link parameters that were set to the Controller.
1
Right-click node 1 device on the
Network Configuration Pane and
select Parameter - Download.
The dialog box on the right is
displayed. Click the Yes Button.
2
The tag data link parameters are
downloaded from the Network
Configurator to the Controller.
4
The dialog box on the right is
displayed. Click the OK Button.
79

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
