2-3
2 System Configuration
NJ-series CPU Unit Hardware User’s Manual (W500)
2-1 Basic System Configuration
2
NJ-series Power Supply Unit
NJ-series CPU Unit
EtherCAT slaves
NJ-series Power Supply Unit
ADRADR
EtherCAT Slave Terminal
EtherCAT
CJ-series Unit Configuration
EtherCAT
Network Configuration
CPU Rack
(I/O Control Unit)
CJ-series Configuration Units
(Basic I/O Units, Special
I/O Units, and CPU Bus Units)
CJ-series Configuration Units
(Basic I/O Units, Special
I/O Units, and CPU Bus Units)
End Cover
End Cover
SD Memory Card
(I/O Interface Unit)
Expansion Rack

Omron NJ301-1200 Specifications

General

Model	NJ301-1200
Memory Capacity	512 MB
Number of Axes Controlled	16 axes
Cycle Time	1 ms
Ethernet Ports	2
Built-in EtherNet/IP port	Yes
Built-in EtherCAT port	Yes
SD Memory Card Slot	Yes
Power Supply	24 VDC
Operating Temperature	0 to 55 °C
CPU Type	Intel Atom
I/O Capacity	Up to 256 points
EtherCAT Refresh Cycle	1 ms
Programming Language	IEC 61131-3 (LD, ST, FBD, SFC, IL)
