Appendix 1 Specifications
•
1:1 NT Link
Item Specifications
Communications standards Conforms to EIA RS-232C.
Connectors D-Sub female 9-pin connector (Serial ports A and B)
Number of Units connected 1:1
Transmission distance Up to 15 m. (See note 1.)
• 1:N NT Links
Item Specifications
Communications standards Conforms to EIA RS-232C.
Connectors D-Sub female 9-pin connector
(Serial ports A and B)
Number of Units connected 1:1 to 8
Transmission distance Up to 15 m. (See note 2.)
Note 1. When using an NS-AL002 Adapter, the transmission distance is as follows:
RS-422A cable: Up to 500 m total extended length.
2. The NS-AL002 is required when connecting two or more PTs to the host.
RS-422A cable: Up to 500 m total extended length.
• Bar Code Reader
Item Specifications
Communications
standards
Conforms to EIA RS-232C.
Communications
settings
Start-stop synchronization
Baud rate: 4,800, 9,600, or 19,200 bps
Data length: 7 or 8 bits
Stop bits: 1 or 2 bits
Parity: None, odd, or even
Flow control: RS/CS control
Ports that can be
connected
Either port A or port B only.
Number of Units
connected
1:1
Using PT serial port and D-Sub 6-pin Using external power supply Transmission dis-
tance
2 m 15 m
Communications
protocol
No protocol mode
Data format
[STX] Data (0 to 40 bytes) [ETX]
Using PT serial port and D-Sub 6-pin Using external power supply Power supply
5 V ±5% 250 mA max. Depends on Bar Code Reader
specifications.
● Ethernet Specifications (NS12-TS01(B)-V1, NS10-TV01(B)-V1, NS8-
TV@1(B)-V1, NS5-SQ01(B)-V1, NS5-SQ01(B)-V2, NS5-TQ0@(B)-V2, NS5-
MQ0@(B)-V2)
Item Specifications
Conformance standards Conforms to IEEE 802.3 / Ethernet (10/100Base-T).
Transmission medium 2 pair Cat 3 UTP 22 to 26AWG, Cat 5, Cat 5e, Cat 6
Transmission distance 100 m (node-to-hub and hub-to-hub)
Connector 8-pin modular connector
A-8
