3-7 Installing the Video Input Unit
● Removing the Video Input Connector
1. Unlock the BNC socket on the camera’s video output cable by twisting it counterclockwise
while pushing it.
Twist counterclockwise
Push
Push
2. After unlocking the BNC socket, pull it out.
Pull out
3-35
