Appendix 8 Standard Models
CPU Units That Connect in 1:1 NT Links via RS-232C to PT Serial Ports
PLC Series CPU Units with built-in 1:1 NT Link
functionality
CPU Units that connect via op-
tional Communications Boards
C200HS-CPU21
C200HS-CPU23
C200HS-CPU31
C200HS-CPU33
---
C200HE-CPU42 (-Z) C200HE-CPU32 (-Z) (See note 1.)
C200HE-CPU42 (-Z) (See note 1.)
C200HG-CPU33(-Z)
C200HG-CPU43(-Z)
C200HG-CPU53(-Z)
C200HG-CPU63(-Z)
C200HG-CPU33(-Z) (See note 1.)
C200HG-CPU43(-Z) (See note 1.)
C200HG-CPU53(-Z) (See note 1.)
C200HG-CPU63(-Z) (See note 1.)
C200HX-CPU34(-Z)
C200HX-CPU44(-Z)
C200HX-CPU54(-Z)
C200HX-CPU64(-Z)
C200HX-CPU65-Z
C200HX-CPU85-Z
C200HX-CPU34(-Z) (See note 1.)
C200HX-CPU44(-Z) (See note 1.)
C200HX-CPU54(-Z) (See note 1.)
C200HX-CPU64(-Z) (See note 1.)
C200HX-CPU65-Z
C200HX-CPU85-Z
CQM1-CPU41-V1
CQM1-CPU42-V1
CQM1-CPU43-V1
CQM1-CPU44-V1
CQM1-CPU45-EV1
---
CPM1A-10CD@-@ (-V1)
CPM1A-20CD@-@ (-V1)
CPM1A-30CD@-@ (-V1)
CPM1A-40CD@-@ (-V1)
---
CPM2A-30CD@@-@
CPM2A-40CD@@-@
CPM2A-60CD@@-@
---
CPM2C-10@@@@@@-@ (See note 4.)
CPM2C-20@@@@@@-@ (See note 4.)
---
C Series
CQM1H-CPU21 (See note 2.)
CQM1H-CPU51 (See note 2.)
CQM1H-CPU61 (See note 2.)
---
CV Series
(See note 3.)
CV500-CPU01-V1
CV1000-CPU01-V1
CV2000-CPU01-V1
---
CVM1 Series
(See note 3.)
CVM1-CPU01-V2
CVM1-CPU11-V2
CVM1-CPU21-V2
---
Note 1. A C200HW-COM02/COM04/COM05/COM06-V1 Communications Board is required.
2. A CQM1H-SCB41 Serial Communications Board is required.
3. Connection is not possible to CVM1/CV-series PLC CPU Units without "-V1" in the
model number.
4. A CS1W-CN118 Conversion Cable or XW2Z-200T-2 Cable with connector must be used
for the connection.
Reference • CS-series CPU Units cannot connect to 1:1 NT Links, but a 1:1 connection can be
made using 1:N NT Links (normal or high-speed). Refer to 4-2 1:N Host Connec-
tion and 4-3 High-speed 1:N NT Link for details.
A-43
