Appendix 8 Standard Models
● CPU Units That Connect in 1:1 NT Links via RS-422A to PT Serial Ports
PLC Series CPU Units with built-in 1:1 NT Link functionality
C200HE-CPU32 (-Z) (See note 1.)
C200HE-CPU42 (-Z) (See note 1.)
C200HG-CPU33 (-Z) (See note 1.)
C200HG-CPU43 (-Z) (See note 1.)
C200HG-CPU53 (-Z) (See note 1.)
C200HG-CPU63 (-Z) (See note 1.)
C200HX-CPU34 (-Z) (See note 1.)
C200HX-CPU44 (-Z) (See note 1.)
C200HX-CPU54 (-Z) (See note 1.)
C200HX-CPU64 (-Z) (See note 1.)
C200HX-CPU65-Z (See note 1.)
C200HX-CPU85-Z (See note 1.)
C Series
CQM1H-CPU51 (See note 2.)
CQM1H-CPU61 (See note 2.)
CV Series (See note 3.) CV500-CPU01-V1
CV1000-CPU01-V1
CV2000-CPU01-V1
CVM1 Series (See note 3.) CVM1-CPU01-V2
CVM1-CPU11-V2
CVM1-CPU21-V2
Note 1. A C200HW-COM03-V1 or C200HW-COM06-V1 Communications Board is required.
2. A CQM1H-SCB41 Serial Communications Board is required.
3. Connection is not possible to CVM1/CV-series PLC CPU Units without "-V1" in the model
number.
Reference • NS-series RS-485 (two-wire) communications are used to connect to an OMRON
Temperature Controller. The NS-AL002 cannot be used with the NT-series PTs or
PLCs. Connect using RS-422A (4-wire).
● CPU Units That Connect to PTs in Standard 1:N NT Links
Model Specifications
C200HE/HG/HX Series With RS-232C connector (switching/9-pin type)
CQM1H Series With RS-232C connector (9-pin type)
CS Series With RS-232C connector (9-pin type)
CJ Series With RS-232C connector (9-pin type)
A-44
