Specifying the Display Method
Specify the display method for the screens as indicated in the table below.
Setting Item Function
Setting
Options
Display of Lamp/
Touch SW No.
Allows designation of whether the bit number of the lamp bit set for a lamp or touch
switch is displayed or not.
The display format is as follows Ljfffffff (j: area type, fffffff
: bit
number).
ON, OFF*
Display of Memory
Table Entry Num-
ber
Allows designation of whether the table entry numbers in numeral and character string
memory tables are displayed or not.
The display format for the numeral memory table is Nffff and the display format
for the character string memory table is Sffff.
This function is valid for the following display elements.
- Numeral displays
- Character string displays
- Bar graphs
- Numeral setting input fields (including thumbwheel type)
- Character string input fields
ON, OFF*
Display of image/
Library No.
Allows designation of whether image/library code numbers are displayed or not. ON, OFF*
Display of Broken
Line Frame
Allows designation of whether or not broken line frames are displayed around the dis-
play elements for showing the positions registered.
ON, OFF*
* Default (factory) setting
Reference: Each
setting of the screen data check is ef
fective only on this
menu. Exiting from
this
screen data check menu resets the settings to the default (all the settings are
set to OFF).
Operations on the SCREEN DAT
A CHECK Screen
The function shown below can be set on the SCREEN DATA CHECK screen.
Use
this function as required when displaying complex screens on which multi
-
ple display elements have been registered overlapping each other.
a)
Equivalent to 2 touch switches (18 mm)
c)
b) Equivalent to 2 touch switches (18 mm)
a) Display the previous display element on the upper most portion of the
screen in the order in which the display elements were registered (ex-
cluding fixed display elements).
b) Display
the next display element on the upper most portion of the screen
in the order in which the display elements were registered (excluding
fixed display elements).
c) Return to the screen on which screens are specified.
