6-3SectionOperation Modes and the System Menu
107
6-3-2 Menu Tree
The System Menu allows the various functions of the NT21 to be executed by
using
touch switches displayed on the touch panel. The menu tree, starting from
the System Menu, is shown below.
For
details on System Menu operations, refer to 6-3-3 Operations with the Sys -
tem Menu (page 108).
The
menu tree may dif fer according to the system program installed in the NT21.
The menu tree for the system program that is installed in the NT21 on shipment
is shown below.
SYSTEM INSTALLER MODE
Exit System Installer
Download System Program (page 119)
Change System Settings (page 120)
Erase Screen Data (page 121)
SYSTEM MENU
Quit
Transmit Mode (page 123)
Maintenance Mode
Expansion Mode
MAINTENANCE
MODE MENU
Quit
Memory
Init.
Memory Switch
Calendar Check (page 147)
PT Settings (page 149)
Display History
Alarm History
Screen Data Disp. (page 153)
I/O Check
I/O CHECK MENU
Quit
I/F Check
Device Check
I/F CHECK MENU
Quit
Tool Comm. (page 161)
Comm. Port A (page 163)
Comm. Port B (page 163)
DEVICE CHECK MENU
Quit
Buzzer Check (page 157)
LED Check (page 158)
LCD Check (page 158)
Backlight Check (page 158)
Screen Memory (page 159)
Touch Switch (page 160)
Battery (page 160)
MEMORY INIT . MENU
Quit
Screen Data (page 110)
Display History (page 112)
Alarm History (page 113)
Recipe Table (page 117)
Memory Table (page 114)
Memory Switch (page 116)
MEMORY
SWITCH MENU
Start-up W ait Time (page 136)
Key Press Sound (page 136)
Buzzer Sound (page 137)
Battery Low Check (page 137)
Screen Saver Movement (page 138)
Hist. Disp. Method (page 139)
Resume Function (page 140)
Comm. Auto-return (page 141)
Time-out Interval (page 142)
Retry Counts (page 142)
Comm. A Method (page 125)
Comm. B Method (page 125)
DISPLAY HISTORY MENU
Quit
Sort by Occurrence (page 150)
Sort by Frequency (page 150)
ALARM HISTORY MENU
Quit
Sort by Occurrence (page 151)
Sort by Frequency (page 151)
EXPANSION
MODE MENU
Quit
Programming Console Function (page 165)
Version Display (page 171)
