6-12SectionProgramming Console Function
168
*2: The CPM2C-CN111 Connecting Cable splits the PC’s Communication Port into a
RS-232C port and a peripheral port.
*3: An RS-232C cable cannot be directly connected to the peripheral port. An
RS-232C adapter (CPM1-CIF01) is required.
*4: The RS-232C cable cannot be directly connected to the peripheral port. An
RS-232C Adapter (CS1W-CN118) is required.
Reference: Note
that the Programming Console function cannot be used
with CPM1, CQM1,
and C200HX/HG/HE PCs of the following lot numbers.
CPM1: jjj5, jj*6
where * is a number in the range 1 to 9 or the letter X or Y.
CQM1: jjj3, jjj4, jjj5, jj
*6
where * is a number in the range 1 to 9 or the letter X or Y.
C200HX/HG/HE: jjj5 jj*6
where * is a number in the range 1 to 9 or the letter X or Y.
6-12-2 Connection Method
The
connection method is exactly the same as for the 1:1 NT Link. Refer to
Sec-
tion
4 Connecting to the Host from the RS-232C Port
or
Section
5 Connecting to
the Host from the RS-422A/485 Port for details on connecting to the PC.
* When using the Programming Console function with a CQM1H, turn ON pin 7 of
the DIP switch on the front of the CQM1H’s CPU Unit.
The connection method is the same as for the 1:1 NT Link. With a CPM1, con
-
nect the RS-232C cable to the peripheral port via a CPM1-CIF01 RS-232C
Adapter or CPM1-CIF11 RS-422A Adapter.
Refer
to
Section
4 Connecting to the Host from the
RS-232C Port
or
Section
5
Connecting
to the Host from the RS-422A/485 Port
for details on connecting
to
the
PC.
The
connection method is the same as for the 1:1 NT Link. Connect to the
PC’
s
communications
connector with a CPM2C-CN1
1
1, CS1W
-CN114/1
18 Connect
-
ing
Cable, a CPM1-CIF01 RS-232C Adapter
, or a CPM1-CIF1
1 RS-422A Adapt
-
er.
Refer
to
Section
4 Connecting to the Host from the
RS-232C Port
or
Section
5
Connecting
to the Host from the RS-422A/485 Port
for details on connecting
to
the
PC.
* When using the Programming Console function with a CPM2C, turn ON pin 2 of
the DIP switch on the front of the CPM2C’s CPU Unit.
The
connection method is exactly the same as
for the 1:N NT Link (standard or
high-speed).
Refer to
Section
4 Connecting to the Host from the RS-232C
Port
or Section 5 Connecting to the Host from the RS-422A/485 Port for details on
connecting to the PC. The standard or high-speed 1:N NT Link can be used.
The
Programming Console function can be used only
when the PT’
s unit num
-
ber is set to 0. Only one Unit using the Programming Console function can be
connected
to each of the PC’
s ports (built-in RS-232C port and peripheral port).
With the CS1G/CS1H, CS1G-H/CS1H-H, and CJ1G PCs, the Programming
Console
function can be used simultaneously at both the built-in RS-232C port
and peripheral port. Furthermore, the Programming Console function can be
started
at the RS-232C port while a Programming Console is connected to the
peripheral port.
CQM1, CQM1H,
C200HX/HG/HE(-ZE), or
SRM1
CPM1 or CPM2A
CPM2C
CS1G/CS1H,
CS1G-H/CS1H-H, or
CJ1G
To Next Page
