4-1SectionConnecting to the RS-232C Port at the Host
55
Using the 1:N NT Link
Compatible Host Units
The
OMRON PCs that can be connected using the 1:N NT Link are the CS-se
-
ries
(CS1G/H or CS1G/H-H), CJ-series CJ1G, C-series C200HX/HG/HE(-Z)E,
CQM1H,
and SRM1 only
. With the CS/CJ-series PCs, it is possible to connect a
1:N NT Link using a CS1W-SCU21 or CJ1W-SCU41 Serial Communications
Unit.
Check the model and series of the PC as well as the model of Serial Commu-
nications Board or Unit being used before making the connections.
The hosts that can be connected to the NT21 by the 1:N NT Link using the
RS-232C ports of both Units are indicated in the table below.
PC Series
CPU Units with Built-in
NT Link Function
CPU Units Connectable
with Communications
Board or Unit
(*1)
Connectable
to
CS Series
CS1G-CPU42/43/44/
45-EV1
CS1H-CPU63/64/65/
66/67-EV1
CS1G-CPU42H/43H/44H/
45H
CS1H-CPU63H/64H/65H/
66H/67H
CS1G-CPU42/43/44/
45-EV1
CS1H-CPU63/64/65/
66/67-EV1
CS1G-CPU42H/43H/44H/
45H
(*1)
CS1H-CPU63H/64H/65H/
66H/67H
(*1)
CS1G
CS1H
CS1G-H
CS1H-H
CJ Series CJ1G-CPU44/45 CJ1G-CPU44/45
(*2)
CJ1G
C200HE-CPU42-(Z)E
C200HE-CPU32-(Z)E
(*3)
C200HE-CPU42-(Z)E
(*3)
C200HE
(-Z)E
C200HG-CPU43-(Z)E
C200HG-CPU63-(Z)E
C200HG-CPU33-(Z)E
(*3)
C200HG-CPU43-(Z)E
(*3)
C200HG-CPU53-(Z)E
(*3)
C200HG-CPU63-(Z)E
(*3)
C200HG
(-Z)E
C Series
C200HX-CPU44-(Z)E
C200HX-CPU64-(Z)E
C200HX-CPU65-ZE
C200HX-CPU85-ZE
C200HX-CPU34-(Z)E
(*3)
C200HX-CPU44-(Z)E
(*3)
C200HX-CPU54-(Z)E
(*3)
C200HX-CPU64-(Z)E
(*3)
C200HX-CPU65-ZE
(*3)
C200HX-CPU85-ZE
(*3)
C200HX
(-Z)E
---
CQM1H-CPU51
(*4)
CQM1H-CPU61
(*4)
CQM1H
CompoBus/S
Master
Control Unit
SRM1-C02-V2 --- SRM1
*1 A CS1W-SCB21 or CS1W-SCB41 Serial Communications Board or
CS1W-SCU21 Serial Communications Unit is required.
*2 A CJ1W-SCU41 Serial Communications Unit is required.
*3 One of the following Communication Boards is required:
C200HW-COM02/COM04/COM05/COM06 (-EV1)
*4 A CQM1H-SCB41 Serial Communications Board is required.
Reference: The
-V1 versions of CS-series PCs and CJ-series PCs
support the high-speed
1:N
NT Link as well as the
standard 1:N NT Link. Furthermore, the high-speed
1:N
NT Link can be used in earlier versions of CS-series PCs by installing a new
version of Serial Communications Board or Unit. For details, refer to
Using the
High-speed 1:N NT Link (page 60).
