4 Installation and Wiring

4 - 36

NX-series Digital I/O Unit User’s Manual (W521)

This is the wiring for three-wire sensors.

 PNP Type Input Units

This is the wiring for contact output type external devices.

IOG

IOV

IOG

IOV

Output

Three-wire sensor

DC Input Unit

Communications Coupler Unit or

Additional I/O Power Supply Unit

IOG

IOV

IOG

IOV

Contact output

DC Input Unit

Communications Coupler Unit or

Additional I/O Power Supply Unit
