5 - 15
5 I/O Refreshing
NX-series Digital I/O Unit User’s Manual (W521)
5-2 I/O Refreshing Methods
5
5-2-6 Synchronous Output Refreshing
Set the following items.
Adding to the NX Unit Configuration
Enable the distributed clock in the EtherCAT slave parameters on the EtherCAT Coupler Unit that is
added to the EtherCAT network configuration and add the NX Units that support synchronous I/O
refreshing to the NX Unit configuration.
Setting the Task Period
Set the task period of the primary periodic task.
With the primary periodic task in Configurations and Setup - Task Settings, select the task period in
the Period/Execution Conditions from the list.
At this time, set the primary period to a task period in which the value that is greater than the I/O
refresh cycle of the NX bus that is calculated by the Sysmac Studio.
A warning is given if you set the primary period to a task period in which the value that is smaller
than the I/O refresh cycle of the NX bus that is calculated by the Sysmac Studio.
Refer to the NX-series EtherCAT Coupler Unit User’s Manual (Cat. No. W519) for a warning on the
task periods.
Settings
To Next Page
