5 I/O Refreshing
5 - 16
NX-series Digital I/O Unit User’s Manual (W521)
This uses the I/O ports of the output set values.
 Two-point Output Units
 Four-point Output Units
 Eight-point Output Units
 Sixteen-point Output Units
 Thirty-two-point Output Units
I/O Port
I/O port name Type R/W Name Description
Default
value
Output Bit 00 BOOL RW Output Bit 00 The output set value for output bit 00. FALSE
Output Bit 01 BOOL RW Output Bit 01 The output set value for output bit 01. FALSE
I/O port name Type R/W Name Description
Default
value
Output Bit 00 BOOL RW Output Bit 00 The output set value for output bit 00. FALSE
Output Bit 01 BOOL RW Output Bit 01 The output set value for output bit 01. FALSE
Output Bit 02 BOOL RW Output Bit 02 The output set value for output bit 02. FALSE
Output Bit 03 BOOL RW Output Bit 03 The output set value for output bit 03. FALSE
I/O port name Type R/W Name Description
Default
value
Output Bit 8 bits BYTE RW Output Bits 8 bits The output set values for 8 bits. 00 hex
I/O port name Type R/W Name Description
Default
value
Output Bit 16 bits WORD RW Output Bits 16 bits The output set values for 16 bits. 0000 hex
I/O port name Type R/W Name Description
Default
value
Output Bit 32 bits DWORD RW Output Bit 32 bits The output set values for 32 bits.
00000000
hex
