7 Digital Output Units
NX-series Digital I/O Unit User’s Manual (W521)
7-3 List of Settings
7
 Eight-point Output Units
 Sixteen-point Output Units
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Load Rejection Output
for Output Bit (8 bits)
Set the output at load OFF
in units of 8 bits.
Bit 0: Setting for output bit
00
Bit 1: Setting for output bit
01
Bit 2: Setting for output bit
02
Bit 3: Setting for output bit
03
Bit 4: Setting for output bit
04
Bit 5: Setting for output bit
05
Bit 6: Setting for output bit
06
Bit 7: Setting for output bit
07
FALSE: OFF
TRUE: Hold the present
value.
00 hex 00
to FF
hex
 5011
hex
01 hex P. 7-12
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Load Rejection Output
for Output Bit (16 bits)
Set the output at load OFF
in units of 16 bits.
Bit 0: Setting for output bit
00
Bit 1: Setting for output bit
01
•
•
•
Bit 15: Setting for output
bit 15
FALSE: OFF
TRUE: Hold the present
value.
0000
hex
0000
to
FFFF hex
 5012
hex
01 hex P. 7-12
