7 - 13
7 Digital Output Units
NX-series Digital I/O Unit User’s Manual (W521)
7-4 Function
7
7-4-2 Load Rejection Output Setting
 Eight-point Output Units
 Sixteen-point Output Units
 Thirty-two-point Output Units
All Digital Output Units
Setting name Description
Default
value
Unit
Load Rejection Output for
Output Bit (8 bits)
Set the output at load OFF in units of 8 bits.
Bit 0: Setting for output bit 00
Bit 1: Setting for output bit 01
Bit 2: Setting for output bit 02
Bit 3: Setting for output bit 03
Bit 4: Setting for output bit 04
Bit 5: Setting for output bit 05
Bit 6: Setting for output bit 06
Bit 7: Setting for output bit 07
FALSE: OFF
TRUE: Hold the present value.
00 hex 
Setting name Description
Default
value
Unit
Load Rejection Output for
Output Bit (16 bits)
Set the output at load OFF in units of 16 bits.
Bit 0: Setting for output bit 00
Bit 1: Setting for output bit 01
•
•
•
Bit 15: Setting for output bit 15
FALSE: OFF
TRUE: Hold the present value.
0000 hex 
Setting name Description
Default
value
Unit
Load Rejection Output for
Output Bit (32 bits)
Set the output at load OFF in units of 32 bits.
Bit 0: Setting for output bit 00
Bit 1: Setting for output bit 01
•
•
•
Bit 31: Setting for output bit 31
FALSE: OFF
TRUE: Hold the present value.
00000000
hex

Target NX Units
