NX-series Digital I/O Unit User’s Manual (W521)
A-5 List of NX Objects
A
A-5-2 Digital Input Units
*1. The default value and data range for Number of Entries are as follows.
*2. Detailed data for Input Bit 32 bits are as follows.
Bit 0: Input Bit 00
Bit 1: Input Bit 01
·
·
·
Bit 31: Input Bit 31
*1. The default value and data range for Number of Entries are as follows.
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6003  DWORD Input  
00 Number of Entries
*1 *1
 USINT RO Not
possi
ble

01 Input Bit 32 bits 00000000
hex
00000000 to
FFFFFFFF
hex
*2
 DWORD RO Possi
ble

NX Units Default value Data range
NX-ID6142-5 1 1 (fixed)
Other models 0 0 (fixed)
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6010  Time Stamp  
00 Number of Entries
*1 *1
 USINT RO Not
pos-
sible

01 Input Bit 00 Time Stamp 0 0 to
+18446744073
709551615
ns ULINT RO Pos-
sible

02 Input Bit 01 Time Stamp ULINT RO Pos-
sible

03 Input Bit 02 Time Stamp ULINT RO Pos-
sible

04 Input Bit 03 Time Stamp ULINT RO Pos-
sible

NX Units Default value Data range
NX-ID3344/ID3444 4 4 (fixed)
Other models 0 0 (fixed)
