Omron NX-OD5256 User Manual

Appendices
A - 84
NX-series Digital I/O Unit User’s Manual (W521)
*1. The default value and data range for Number of Entries are as follows.
*2. Detailed data for Input Bit 8 bits are as follows.
Bit 0: Input Bit 00
Bit 1: Input Bit 01
·
·
·
Bit 7: Input Bit 07
*1. The default value and data range for Number of Entries are as follows.
*2. Detailed data for Input Bit 16 bits are as follows.
Bit 0: Input Bit 00
Bit 1: Input Bit 01
·
·
·
Bit 15: Input Bit 15
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6001  BYTE Input  
00 Number of Entries
*1 *1
 USINT RO Not
pos-
sible

01 Input Bit 8 bits 00 hex
00 to FF hex
*2
 BYTE RO Pos-
sible

NX Units Default value Data range
NX-ID4342/ID4442 1 1 (fixed)
Other models 0 0 (fixed)
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
6002  Word Input  
00 Number of Entries
*1 *1
 USINT RO Not
pos-
sible

01 Input Bit 16 bits 0000 hex 0000 to FFFF
hex
*2
 WORD RO Pos-
sible

NX Units Default value Data range
NX-ID5142-5/ID5342/ID5442 1 1 (fixed)
Other models 0 0 (fixed)

Omron NX-OD5256 Specifications

General

Brand	Omron
Model	NX-OD5256
Category	I/O Systems
Language	English
