This section lists other objects.
*1. The default value and data range for Number of Entries are as follows.
*2. The meaning of the set values for Input Filter Value Setting is as follows.
*3. The meaning of the set values for Input Filter Mode Setting is as follows.
Other Objects
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
5000  Input Filter Setting  
00 Number of Entries
*1 *1
 USINT RO Not
pos-
sible

01 Input Filter Value Setting 3
0 to 11
*2
 USINT RW Not
pos-
sible
Y
02 Input Filter Mode Setting 0
0/1
*3
 USINT RW Not
pos-
sible
Y
NX Units Default value Data range
NX-MD6121-5/MD6256-5 2 2 (fixed)
Other models 0 0 (fixed)
Set value Meaning
0No Filter
1 0.25 ms
2 0.5 ms
31 ms
42 ms
54 ms
68 ms
7 16 ms
8 32 ms
9 64 ms
10 128 ms
11 256 ms
Set value Meaning
0 Enable ON Filter and OFF Filter
1 Enable Only OFF Filter
