A - 103
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-5 List of NX Objects
A
A-5-4 Digital Mixed I/O Units
*1. The default value and data range for Number of Entries are as follows.
*2. The detailed data and meaning of the set values for Load Rejection Output for Output Bit (16 bits) are as follows.
Bit 0: Load Rejection Output for Output Bit 00
Bit 1: Load Rejection Output for Output Bit 01
·
·
·
Bit 15: Load Rejection Output for Output Bit 15
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
5012 ï€ Load Rejection Word Set-
ting
ï€ï€ ï€ï€ï€ï€ï€
00 Number of Entries
*1 *1
ï€ USINT RO Not
pos-
sible
ï€
01 Load Rejection Output for
Output Bit (16 bits)
0000 hex 0000 to FFFF
hex
*2
ï€ WORD RW Not
pos-
sible
Y
NX Units Default value Data range
NX-MD6121-5/MD6256-5 1 1 (fixed)
Other models 0 0 (fixed)
Set value Meaning
0OFF
1 Hold the present value.
