4 Installation and Wiring

4 - 26

NX-series Digital I/O Unit User’s Manual (W521)

1 Place the terminal block hook on the guide at the bottom of the NX Unit and press in on the top

of the terminal block to attach it.

Mount a Terminal Block that is applicable to each Unit model.

Refer to Applicable Terminal Blocks for Each Unit Model on page 3-5 for the applicable Terminal

Blocks.

Attaching a Terminal Block

GuideHook

Introduction3
