Versions
21
NJ/NX-series Database Connection CPU Units User’s Manual (W527)
Checking Unit Versions with the Sysmac Studio
You can use the Sysmac Studio to check unit versions. The procedure is different for Units and for
EtherCAT slaves.
Checking the Unit Version of an NX-series CPU Unit
You can use the Production Information while the Sysmac Studio is online to check the unit version
of a Unit. You can do this for the CPU Unit. For an NX1P2 CPU Unit, you can also check the unit
versions of the NX Units on the CPU Rack and Option Boards.
1. Right-click CPU Rack under Configurations and Setup - CPU/Expansion Racks in the
Multiview Explorer and select Production Information.
The Production Information Dialog Box is displayed.
Checking the Unit Version of an NJ-series CPU Unit
You can use the Production Information while the Sysmac Studio is online to check the unit version
of a Unit. You can do this for the CPU Unit, CJ-series Special I/O Units, and CJ-series CPU Bus
Units. You cannot check the unit versions of CJ-series Basic I/O Units with the Sysmac Studio.
Use the following procedure to check the unit version.
1. Double-click CPU/Expansion Racks under Configurations and Setup in the Multiview Explorer.
Or, right-click CPU/Expansion Racks under Configurations and Setup and select Edit from the
menu.
The Unit Editor is displayed.
2. Right-click any open space in the Unit Editor and select Production Information.
The Production Information Dialog Box is displayed.
To Next Page
